OUTPUT POWER (RMS) @ 14.4 VDC, THD 1%:
6Ch 160 W x 6 (4Ω)
6Ch 290 W x 6 (2Ω)
5Ch 160 x 4 (4Ω) + 580 x 1 (4Ω)
5Ch 290 x 4 (2Ω) + 580 x 1 (4Ω)
4Ch 160 x 2 (4Ω) + 580 x 2 (4Ω)
4Ch 290 x 2 (2Ω) + 580 x 2 (4Ω)
3Ch 580 x 3 (4Ω)
Power supply voltage: 9 - 16 VDC
ldling current (power ON/OFF): 1.8 A / 0.04 mA
Consumption@ 1Ω, 14.4 VDC (Max Musical Power): 75 A
Remote In: 7 - 15 VDC - 1 mA
Distortion - THD (100Hz @ 4Ω): <0,06%
Bandwidth: 10 - 42 kHz
S/N Ratlo (A weighted @ 1 V): 100 dB
Damping factor (100Hz @ 4Ω): 130
Pre-ln sensitivity: 0.2 - 5 VRMS
Pre-ln impedance: 10 kΩ
Load impedance (MIN)
@6Ch: 2Ω
@5Ch: 2Ω + 2Ω + 2Ω +2Ω + 4Ω
@4Ch: 2Ω + 2Ω +4Ω + 4Ω
@3Ch: 4Ω
Adjustable Crossovers yes
lnputs:
A Ch. Pre in
B Ch. Pre in
C Ch. Pre in
Pre-Out: No
Ch. A filters:
MONO IN (on/off) Yes
By-pass Yes
Hi-pass: 50 - 500 Hz / 500 Hz - 5 kHz @ 12 dB/Oct
Ch. B filters:
MONO IN (on/off) Yes
By-pass Yes
Hi-pass: 50 - 500 Hz @ 12 dB/Oct
Band-pass: 50 - 500 Hz / 500 Hz ÷ 5 kHz @ 12 dB/Oct
Ch. C filters:
MONO IN (on-off) Yes
By-pass Yes
Hi-pass: 50 - 500 Hz @ 12 dB/Oct
Lo-pass: 50 - 500 Hz @ 12 dB/Oct
